Quick Intro to Cython

A tourist guide approach to learn Cython in a easy, understandable and practical way.

Why

Python is a beautifully simple, newbie-friendly programming language. Nonetheless, such simplicity often comees with a cost: speed. Python is fast to write but slow to execute, specially if you go into heavier computation stuff, such as algorithms. To speed up, you can extend it with Cython.

What

Cython is a Python compiler that allows to write C extensions. It can compile normal Python code on top of static type declarations to speed up the execution.

Example

We will write a meaningless loop function (iterate and sum for nothing in special really) to showcase the potential of statically type variables with C for known routines.

The first code file will be the Python standard loop.py:

# loop.py, cloop.pyx
import time

def loop_and_add():
    t1 = time.time()
    j = 0
    for i in range(30_000_000):
        if i % 2 == 0 and i % 15 == 0:
            j += i
    t2 = time.time()
    return j, round(t2-t1, 4)

The first test will be to have the same code compiled with Cython. To do that, we duplicate the same file into an cloop.pyx Cython file and create a cloop_setup.py that will handle the cynthonization.

# cloop_setup.py
import distutils.core
import Cython.Build

distutils.core.setup(
    ext_modules = Cython.Build.cythonize("cloop.pyx")
)

After that, run the following in the terminal to generate the compiled code.

$ python cloop_setup.py build_ext --inplace

We now have two importable modules into our python, the original loop and the Cythonized cloop. Let’s try those out.

import loop
import cloop

for i in range(5):
    print(loop.loop_and_add())

#(14999985000000, 2.7513)
#(14999985000000, 2.6421)
#(14999985000000, 2.5611)
#(14999985000000, 2.5821)
#(14999985000000, 2.5908)

for i in range(5):
    print(cloop.loop_and_add())

#(14999985000000, 1.2493)
#(14999985000000, 1.3441)
#(14999985000000, 1.3525)
#(14999985000000, 1.3364)
#(14999985000000, 1.3344)

As you can see, by running cython over the already existing Python code (even without any changes) speeds up this process to close to a half of the time. We can even go further and statically define the types of the variables within the cython .pyx file as a new optimized loop file oloop.pyx.

# oloop.pyx
import time

def loop_and_add():
    # Declare the variable types.
    cdef int i, N
    cdef long j

    t1 = time.time()
    j = 0
    N = 30_000_000
    for i in range(N):
        if i % 2 == 0 and i % 15 == 0:
            j += i
    t2 = time.time()
    return j, round(t2-t1, 4)

We can test that using the same logic as before.

import oloop

for i in range(5):
    print(oloop.loop_and_add())

#(14999985000000, 0.042)
#(14999985000000, 0.0424)
#(14999985000000, 0.0426)
#(14999985000000, 0.0433)
#(14999985000000, 0.0478)

The computation time is now reduced to approximately zero.

The full comparison is repeated now with 100M entries over 5 runs and we achieve the expected results: full Python is much slower, Cythonize raw Python code helps but statically typing the variables is much faster than before.

import loop
import cloop
import oloop

for i in range(5):
    print(loop.loop_and_add())

#(166666683333330, 8.9182)
#(166666683333330, 9.5814)
#(166666683333330, 9.6526)
#(166666683333330, 9.3617)
#(166666683333330, 9.0275)


for i in range(5):
    print(cloop.loop_and_add())

#(166666683333330, 4.492)
#(166666683333330, 4.5549)
#(166666683333330, 4.4763)
#(166666683333330, 4.4895)
#(166666683333330, 4.4776)


for i in range(5):
    print(oloop.loop_and_add())

#(166666683333330, 0.1468)
#(166666683333330, 0.1436)
#(166666683333330, 0.1483)
#(166666683333330, 0.1488)
#(166666683333330, 0.1497)

In a Nutshell

Get the python code. Define the types and function calls inside C whenever possible. Setup the Cythonizer with distutils. Import the optimized module.

Additionally, Cython requires you to have C compiler (protip: use VSCode + WSL on Windows).

Tips and Tricks

Performance Report

Cython has a nice, built-in functionality that allows to provide hints for code blocks where the execution will take longer based on code execution calls. To test this, you can simply run cython -a mycythonfile.pyx and check the generated html.

Variable Types

Cython can use ìnt, float, long, char, struct, bint.

Function Declarations

Functions defined with def are visible to other Python code. cdef are only visible to Cython/C and execute much faster, so use them if those functions are only called within the Cython module. cpdef allows for compatibility with both Python and C, in a way that C can access the declared function at full speed but with some overhead (more code generated and more call overhead).
